0-50W/200W/500W Inverter Module 12V to 220V DC-AC Step-Up Booster Board with Multi-Level Safety Protection for Projectors Rice

Quantity : 1 High-concerned chemical : none Package : SOP is_d : Yes Supply Voltage : DC 12-14.5V Type : Voltage Regulator Origin : Mainland China Condition : New Operating Temperature : 0-50C

50-100W 1. Supports 12-14.5V input, stable output of 220V, stable and efficient voltage 2. It can output 100W (with fan cooling) to meet the needs of various low-power electrical appliances 3. Built in overheating and overload protection, safe and reliable operation, and extended life 4. Compatible with various daily electrical devices such as televisions, monitors, lighting, and charging 5. Output 50Hz pure correction wave, widely compatible with various household appliances such as fans

200W 1. Supports 12-14.5V input, stable output of 220V, stable and efficient voltage 2. Maximum power of 200W (with fan), meeting the needs of various household appliances 3. Built in overheating and overload protection, safe and reliable operation, and extended life 4. Equipped with a switch and a reserved fan interface, it is easy to use and has better heat dissipation effect 5. Wide range of application scenarios, suitable for various appliances such as fans and televisions

500W 1. Continuous 300W peak 500W, easily driven by high-power appliances 2. Built in multiple safety protections to prevent the risk of low voltage overcurrent and short circuit 3. Reserved temperature control fan interface, automatic heat dissipation at 65 ℃ without overheating 4. Comes with a convenient power switch, one click control without the need for repeated plugging and unplugging 5. Widely used in multiple scenarios, compatible with projectors, rice cookers, and other electrical appliances 50-100W Product Parameters: Product Name: Boost Inverter Module Input voltage: DC 12-14.5V Output voltage: AC 220V Frequency: 50Hz Power: 50-100W (with fan cooling, it can reach up to 100W) Output: Only small power appliances can be connected, and the output cannot exceed 50W Description: Supports the use of fan motor products, computer displays, low-power televisions, mobile phone charging, electric fans, energy-saving lamps, tungsten filament lamps and other low-power electrical appliances, with overheating and overload protection. Wiring operation: Input: Connect to DC 12V-14.5V, the positive and negative poles cannot be reversed, and the input line should not be less than 1.5 square meters Output: 220V AC, can use any electrical appliances within the specified wattage range: light bulb lighting, mobile phones, monitoring, audio, routers, set-top boxes, projectors, televisions, fans, water pumps, etc. (any electrical appliances within the specified wattage range can be used) Notes: 1. The input of this product can only be connected to a 12-14.5V battery, which can be converted to a 220V power supply. The positive and negative poles of the input cannot be reversed. The input and output must be connected first and checked for accuracy before connecting the battery to power on 2. If the output power exceeds 100W, a fan must be added for heat dissipation

200W Product Parameters: Product Name: DC-AC Step up Transformer Module Input voltage: DC 12-14.5V Output voltage: AC 220V Frequency: 50Hz Output power: Can only connect low-power appliances, output cannot exceed 150W, 200W Max (with fan cooling can reach 200W) Fan interface: Reserved fan interface, compatible with DC 12V fan (with PH2.0-2P plug) Application scenarios: bulb lighting, mobile phones, surveillance, audio, routers, set-top boxes, projectors, televisions, fans, fish tank water pumps, etc. (any electrical appliance within the specified wattage can be used) Wiring operation: Input: Connect to DC 12V-14.5V, the positive and negative poles cannot be reversed, and the input line should not be less than 4 square meters Output: 220V AC power Notes: 1. The input of this product can only be connected to a 12-14.5V battery, which can be converted to a 220V power supply. The positive and negative poles of the input cannot be reversed. The input and output must be connected first and checked for accuracy before connecting the battery to power on 2. If the output power exceeds 150W, a fan must be added for heat dissipation

500W Product Name: DC-AC Step-Up Transformer Module Input Voltage: DC 12-14.5V Output Voltage: AC 220V Frequency: 50Hz Input Current: >30A Output Power: Continuous 300W, 500W Max (500W achievable with fan cooling) Fan Interface: Reserved for temperature-controlled/non-temperature-controlled fans Temperature-Controlled Fan Activation: Activates around 65°C Applications: Supports fans, aquarium pumps, desktop computers, e-bike charging, TVs, projectors, electric blankets, small hand drills, rice cookers, etc. (Any appliance within specified wattage limits) Wiring Instructions: Input: Connect to DC 12V-14.5V. Do not reverse polarity. Input cable must be no less than 6mm². Battery capacity must be 50A or higher. Output: 220V AC Precautions: 1. This product accepts only 12-14.5V batteries as input, converting to 220V AC output. Do not reverse polarity. Ensure all connections are correct before connecting the battery. 2. Output exceeding 300W requires a cooling fan. 3. Input cable must be ≥6mm² with a battery rated ≥50A. Continuous 500W operation requires fan cooling; without cooling, limit to ≤300W.

Package include: Module x1（According to the model you have chosen）

50-100W

200W 500W label:yes
